Cosmo PLS 500 User Manual

36
11.5. CONVOGLIATORE DOPPIO - DOUBLE SIDE CONVEYOR
POS. QTY CODICE DESCRIZIONE DESCRIPTION
1 2 303.013 ROND. 8X24 UNI 6593 ZB WASHER 8X24 UNI 6593
2 2 302.005 VOLANTINO FEMM. DM40 M8 KNOB DM40 M8
3 1 620.043 CONVOGLIATORE LATERALE DOPPIO DOUBLE SIDE CONVEYOR
4 2 300.030 VITE TTQST 8X16 UNI 5731 ZB ROUNDHEADED SCREW 10X20 UNI 5731
5 1 300.016 VITE TE M10X20 UNI 5739 ZB HEX. HEAD SCREW M10X20 UNI 5739
6 1 620.222 STAFFA A C SOSTEGNO CONV. C TYPE SUPPORT BRACKET
7 1 303.005 RONDELLA 10X40 UNI 6593 ZB WASHER 10X40 UNI 6593
8 2 301.013 DADO AUT.ALTO M10 ZB SELF-LOCKING NUT M10
9 1 300.003 VITE TE M10X25 UNI 5739 ZB HEX. HEAD SCREW M10X25 UNI 5739
10 2 300.029 VITE TE M8X20 UNI 5739 ZB HEX. HEAD SCREW M8X20 UNI 5739
11 2 303.013 ROND. 8X24 UNI 6593 ZB WASHER 8X24 UNI 6593
12 1 301.013 DADO AUTOBLOC. ALTO M10 ZB SELF-LOCKING NUT M10
13 1 303.015 ROND. 10X20 UNI 6592 ZB WASHER 10X20 UNI 6592
14 1 300.003 VITE TE M10X25 UNI 5739 ZB HEX. HEAD SCREW M10X25 UNI 5739
15 1 620.223 STAFFA ASOLATA SLOTTED SUPPORT
16 1 606.385 LAMIERA PORTELLO SHUTTER
17 1 606.387 MANIGLIA PORTELLO DOOR HANDLE
18 1 305.020 SPINA ELASTIC 3X15 SPRING PIN 3X15
19 1 303.015 ROND. 10X20 UNI 6592 ZB WASHER 10X20 UNI 6592
20 1 301.053 DADO AUT. BASSO M10 SELF-LOCKING NUT M10
21 1 620.106 KIT CONVOGLIATORE LATERALE
DOPPIO
KIT ASSEMBLED DOUBLE
SIDE CONVEYOR
