6
ENGLISH
4. Specifications
Model: CG 330B
Dry weight: 6.7 kg (without fuel and cutting equipment)
Engine: Air-cooled two-stroke engine
Cylinder volume: 32.6 cm
3
Fuel: Oil mixture in gasoline 50:1 (2 %)
Max engine power: 0.9 kW at 6500 rpm (according to ISO 8893)
Max spindle speed: 6500 rpm
Max engine speed: 6500 rpm
Idling speed: 2500 rpm
Direction of rotation: Counter-clockwise (seen from above)
Spark plug: NGK BM6A or Bosch WS8E
Tank volume: 0.75 litres
Cutting equipment:
Nylon thread: Ø 2,4 mm
3-tooth brushwood blade: Ø 255mm, canter bore: 25.4mm, max rpm 9000
Vibration levels (according to
ISO 7916)
Idling 1.20 m/s
2
Full speed 7.5 m/s
2
Sound pressure LwA According to 2000-14/CE 110dB (A)
Sound according to EN 27917 (Ip a av) 96dB (A)
Sound according to ISO 10883 (Lw a av) 107dB(A)
