4-2-6. Chassis Ground: Connect the wire # 8 AWG to vehicle chassis.
WARNING!
Operating the inverter without a proper ground
connection may cause electrical safety hazard.
4-2-7. DC Input Level：Display Input Voltages
LED Status DC 12V DC 24V DC 48V
RED Blink (slow) 10.5~10.9 21.0~21.8 42.0~43.6
RED 10.9~11.3 21.8~22.6 43.6~45.2
ORANGE 11.3~12.0 22.6~24.0 45.2~48.0
GREEN 12.0~14.0 24.0~28.0 48.0~56.0
ORANGE Blink 14.0~14.7 28.0~29.4 56.0~58.8
OVER RED BLINK 14.7q 29.4q 58.8q
4-2-8. AC Input Level：Display Input Status
LED Status AC Input
ORANGE OFF
GREEN ON
4-2-9. Load Level：Display AC Loads (Watts)
LED Status DARK GREEN ORANGE RED
BLINKING
RED
ST1000
0 ~ 50W 50 ~ 330W 330 ~ 750W 750 ~ 960W Over 960W
ST1500
0 ~ 75W 75 ~ 495W 495 ~ 1125W 1125 ~ 1450W Over 1450W
ST2000
0 ~ 100W 100 ~ 660W 660 ~ 1500W 1500 ~ 1920W Over 1920W
ST2500
0 ~ 125W 125 ~ 825W 825 ~ 1875W 1875 ~ 2390W Over 2390W
20
