Page 44
Troubleshooting (Grass Collecting)
Grass Collection (fig. 85)
If your Collector is not picking up satisfactorily,
check the following:
1. The PTO lever is engaged.
2. That the PTO pulley beneath the seat is
turning – if not, call your dealer.
3. That the Collector Belt is not reversed (if it is
correct, the brush revolves against the forward
direction of the tractor (fig. 85).
4. That the Brush Height Adjustment Lever is not
set too high or too low.
5. That there is not a build up of congealed grass
on the leading edge of the Brush Guard.
6. That the Brush is not clogged.
7. That the Collector Belt is not slipping, if it is
then adjust the tension or replace the worn or
damaged belt (see earlier PGC section).
8. That the Collector net is not clogged. If so,
wash or brush with a stiff hand brush.
9. That the Brush is not damaged.
If you are still experiencing difficulties with collection
please contact your dealer.
fig. 85
