Countax Garden Tractor - Specifications

MODEL
ENGINE
DISP
POWER
TORQUE
BORE
STROKE
C300M
C300H
Briggs & Stratton
INTEK OHV
465cc
9.28kw (13hp)
@3600 rpm
24.5NM
@3600 rpm
87.3mm 77.7mm
C38H
Honda OHV
GXV390
389cc
9.7kw (13hp)
@3600 rpm
27.45NM
@2500 rpm
88.0mm 64.0mm
C400H
Briggs & Stratton
Vanguard OHV
480cc
11.2kw (14hp)
@3600 rpm
31.0NM
@2500 rpm
68.0mm 66.0mm
C600H
C600HE
Briggs & Stratton
Vanguard OHV
480cc
11.9kw (16hp)
@3600 rpm
32.5NM
@2400 rpm
68.0mm 66.0mm
C-800HE
Briggs & Stratton
Vanguard OHV
570cc
13.4kw (18hp)
@3600 rpm
40.0NM
@2400 rpm
72.0mm 70.0mm
C550H
Briggs & Stratton
INTEK OHV
389cc
9.7kw (15.5hp)
@3600 rpm
27.45NM
@2500 rpm
88.0mm 64.0mm
SPECIFICATION SUMMARY
DIMENSIONS (approx.)
LENGTH: 1.75m (69”)
LENGTH INC PGC: 2.07m (107”)
HEIGHT: 1.14m (45”)
WIDTH (EXC DECK): 96cm (38”)
WEIGHT (approx.)
TRANSMISSION
C300M: 329kgs (526lbs)
C300H: 241kgs (530lbs)
C38H: 243kgs (535lbs)
C550H: 243kgs (535lbs)
C400H: 243kgs (535lbs)
C600H/HE: 244kgs (537lbs)
C800HE: 261kgs (575lbs)
COLLECTOR: 53kgs (119lbs)
ENGINE LUBRICANT
C300M: 1.4 litres (2.5 Pints)
C300H: 1.4 litres (2.5 Pints)
C38H: 1.1 litres (1.9 Pints)
C550H: 1.1 litres (1.9 Pints)
C400H: 1.65 litres (2.9 Pints)
C600H/HE: 1.65 litres (2.9 Pints)
C800HE: 1.65 litres (2.9 Pints)
TYRE PRESSURES
FRONT:0.8 - 1.1kgF/cm (12 - 16lb PSI) REAR: 0.7 - 1.1kgF/cm (10 - 12lb PSI)
Tuff Torq K55 Hydrostatic Transmission with infinitely variable speed control (sealed for life).
Peerless MST 206/536A Transaxle
Recommended SAE30 or 10W-30 high quality detergent oil classfied for service: SG, SF, SE. Read and follow the
instructions in the engine manufacturer’s handbook.
PRESSURE RECOMMENDED FOR MAXIMUM GRIP - NEVER INFLATE ABOVE MAXIMUM PRESSURES
®
Countax Limited, Countax House, Great Haseley, Oxford OX44 7PF
Tel: (01844) 278800 • Fax: (01844) 278792 • email@countax.com • www.countax.com
All figures are approximate. We reserve the right to change specification without prior notice E&OE
