CountyLine CL-30P-DDF - Wall Mount Installation

24” BARREL FAN
NEVER LEAVE A FAN
UNATTENDED WHILE
OPERATING OR WHILE
CONNECTED TO A POWER
SOURCE
HVF Air Circulator User’s Manual For customer support, call 1-866-641-4540 www.TractorSupply.com
5
If the Wall Mount Kit is applied, the
installer MUST be certain that the
Wall Mount is mounted to a minimum of a 2x4” stud,
and that it is able to support 50 pounds continuously.
1. Attach Wall Mount (item 17 on page 4) to wood stud as
shown below.
2. Slide Wall Bracket L and Wall Bracket R on Large Base
(item 23) onto Wall Mount.
WARNING
Installation and Assembly - Wall Mount (requires flat head screwdriver)
Wall
Wall
Wall Mount (item 17)
Handle Arm (item 20)
Wall Mount
(item 17)
Large Base
(item 23)
Figure 3: Wall Mount installation
