Courtyard HYPH4601-7 - Page 7

B
H
F
E
D
AA
EE
CC
FF
J
J
1-866-771-2663 | Page 7
4. Place the glass tube (H) into the top of the glass
tube ring (B).
reppu eht morf swercs 5M 3 evomeR...666
supporters (J). Place the r
in the previous step onto the upper supporters (J).
Tighten together with 3 M5 screws just removed
from the upper supporters (J).
5. Insert 3 M8 studs (FF) in between lower
radiation screen (F) and upper radiation screen (E).
Fasten the studs with 3 M8 nuts (CC). Then insert
3 M6 studs (EE) between the upper radiation
cap nuts (AA).
