600568 Rel-00065 of 7
PROBLEM SOLUTION
LEDs on Control Pad do not light when
buttons are pressed.
Did not x problem.
Remove Control Pad faceplate.
Remove batteries from battery holder.
Clean battery contacts.
Install new batteries in battery holder.
Reinstall Control Pad faceplate.
Contact local Cover Dealer for service.
PIN entry does not activate Cover
Mechanism, but red LED on Control
Pad is 'ON' when buttons are pressed.
Did not x problem.
Did not x problem.
Power "ON" to Auto Shutoff board
Did not x problem.
Did not x problem.
Enter valid PIN.
If PIN is Valid, Green LED will ash as C (Cover) or U (Uncover) is
pressed.
If PIN is NOT valid, Red LED is 'ON' as C (Cover) or U (Uncover) is
pressed, Re-enter PIN.
Verify that power to the Auto Shutoff board is on.
Typically the Auto Shutoff board and Receiver are located in an enclo-
sure by the pool cover electric motor.
Power to Auto Shutoff board is on if 2 Green LEDs on Auto Shutoff
board are ashing. (see Illustration on page 1).
Turn power "OFF" for 10 sec.
Turn power "ON".
Enter valid PIN.
See RECEIVER RESET instructions. (pg. 3)
See LINK CONTROL PAD AND RECEIVER instructions. (pg. 4)
Contact local Cover Dealer for service.
Coverlink™ Wireless Control
Troubleshoot Guide
ExPLANATION OF CHANNEL AND NETWORK ID
CHANNEL:
The channel controls the frequency at which signals are transmitted. Frequencies range in thirty-two
increments between 903MHz (channel 00) to 926MHz (channel 31). Thus, if signal interference is
observed during cover operation (intermittent or hesitant cover movement) another interference free
channel may be selected.
NETWORK ID:
The network ID allows multiple cover systems (within the same vicinity) to run without interference while
being on the same channel. There are one hundred Network ID (00 to 99). If each cover system is on a
different network ID, they will run interference free from one another on the same channel.
6. TROUBLESHOOT gUIDE
©Cover-Pools Inc.
