Securing Ratchet Tie-Downs
Note: Use these instructions for installing
Door, Back, and Roof Cover.
1. Thread the strap through the Ratchet’s (8)
spindle as far as it will go.
Figure K: Threading Strap through Spindle
2. Insert the S‑hook of the Ratchet into
the hole in the Corner Leg (6).
Figure L: Inserting Hook into Corner Leg
3. Lift and lower the Ratchet’s handle to wind
and tighten the strap onto the spindle.
Figure M: Tightening Ratchet
NOTICE: Excessive tightening will damage
straps, Covers, and Corner Legs.
Releasing Ratchet Tie-Downs
1. Depress the spring‑loaded bar on the handle.
2. Open Ratchet handle completely.
3. Unwind the strap.
Figure N: Releasing Ratchet
Page 10 For technical questions, please call 1-888-866-5797. 62860
SAFETY OPERATION MAINTENANCESETUP
