Others
TROUBLESHOOTING / SPECIFICATION
SPECIFICATION
Product Water Filtration Device
Model CHP-590L CHP-590R
Filtration Method RO(Reverse Osmosis)
Power Supply Refer to the rating plate.
Tank Capacity
Room Water 6 L
Cold Water 3 L
Hot Water 3 L
Total 12 L
Dimension 260 mm(W) × 448 mm(D) × 1 150 mm(H)
Working Temperature 5 °C - 35 °C (41 °F - 95 °F)
Production Rate 189 L/d (25 °C, 0.14 Mpa)
Working Pressure 20 ~ 120 psi (137 ~ 827 kPa) 10 ~ 120 psi (69 ~ 827 kPa)
Net Weight 27 kg 29 kg
• The water amount can be dierentiated according to the water pressure and the water
temperature.
• The water tank capacity is the amount by the size and can be dierent from the extraction
capacity.
• Without any prior notice, all or parts of the product are subject to change for the purpose of
improving the performance of the product.
• Refer to Performance data sheet for individual contaminants, reduction performance and general
operating information.
