Handlebar
90°
Allen key 3
01 Check
Your bike comes with the handlebar
parallel to the wheels and frame.
03 Secure
Use the 3mm Allen key to tighten
the two screws securely as shown.
The torque value is 6 Nm. This will
keep your handlebar in place.
Be sure to use the short end of
the Allen key for the most
tightening force, then test it to
make sure it’s fully secure by
blocking the front wheel between
your legs and trying to move the
handlebar from left to right.
02 Rotate
Turn the handlebar 90° clockwise
until it’s at a right angle to the rest
of the bike. It’s important that the
front brake disc marked in the
diagram ends up on the left side
of the wheel.
If you see the disc brake is sitting
incorrectly on the right-hand side,
turn the fork in the anticlockwise
direction to rectify.
Front
brake disc
