ElectricalGroundingInstructions:
• The rotisserie motor is equipped with a three‐prong grounding plug for your protection against
electricshock.Thisplugmustbeinserteddirectlyintoaproperlygroundedthree‐prongreceptacle.Do
notcutorremovethegroundingprongfromthisplug.
• Therotisserie motormustbeelectricallygroundedinaccordancewith local codesor,intheabsence
of local codes, in accordance with the National Electrical Code, ANSI/NFPA 70‐1990 or Canadian
ElectricalCode,CSAC22.1.
• Donotuseanextensioncordtosupplypowertoyourgrill.Suchusemayresultinfire,electricalshock
orotherpersonalinjury.Donotinstallafuseintheneutralorgroundcircuit.Afuseintheneutralor
ground circuit mayresult in an electricalshock hazard. Donot ground thisappliance to agas supply
pipeorhotwaterpipe.
InstructionforConnectingtheTransformer
1. Transformer for Interior Lights‐Your transformerwill connect on theleft side of your grill (looking at it
fromthefront)andoperatesthelightsinsideyourgrill.Followthepicturesandinsertthewhitemaleplug
into the white female socket, on the leftside of your grill and then plugthe transformer intoa standard
110voutlet.
  
LeftSideofGrillsMalePlugFemaleSocket

2. TransformerforBackLitKnobs–(only onCSLX36 andCSLX42modelswithbacklitknobs)
Yourtransformerwillconnectontheleftsideofyourgrill(lookingatitfromthe front) and operates theLED
lightsbehindknobbezels.Followthepicturesandconnectthetransformer,andthenplugthetransformerinto
astandard110voutlet.ReadbelowinstructionforhowtochangenewLEDs.
RemovetheKnob RemovetheScrews 
