CMP 200® / CMP 200® DR SERIES
X-RAY GENERATOR
SERVICE MANUAL
PREPARED BY:
COMMUNICATIONS & POWER INDUSTRIES CANADA INC.
45 RIVER DRIVE
GEORGETOWN, ONTARIO, CANADA L7G 2J4
TELEPHONE: (905) 877-0161
901471-00
SERVICE MANUAL P/N
901471-01

Table of Contents

Questions and Answers

  • T
    twilliamsNov 4, 2025
    What to do if the CPI Portable Generator displays 'Requested density not programmed'?
    • H
      Hunter BowmanNov 4, 2025
      If the CPI Portable Generator displays a message indicating that the requested density is not programmed, you can try the following: * Select another density or program the requested density step. * Recalibrate the X-ray tube or select a calibrated parameter. * Reset the DAP. * Re-evaluate technique factors and allow the generator to cool if possible, to prevent overheating. * Allow the generator to cool sufficiently to allow the requested exposure. * Select a valid parameter. * Wait for the anode to cool. * Reset the time and date. * Power the unit off and retry the rotor start. * Check for an open filament in the X-ray tube, poor connections in the cathode cable, and fuses on the filament board(s). * If arcing of the X-ray tube is suspected, check the condition of ...

Summary

Chapter 1: Pre-installation

1.2.0 Safety

Details safety precautions, warning symbols, notices, and labels for generator operation and service.

1.3.0 Preparing for Installation

Covers essential pre-installation steps like power, placement, and tools.

Chapter 2: Installation

2.7.0 Low Speed Starter Tube Compatibility

Details compatibility for low-speed starter tubes and H.V. auxiliary boards.

2.8.0 Programming the Dual-Speed Starter

Guides on programming dual-speed starter for X-ray tubes using DIP switches.

2.11.0 Tube mA Auto Calibration

Explains automatic calibration process for X-ray tube mA output.

Chapter 3 C: Interfacing and Programming

3 C.3.0 Generator Programming

Guides on programming generator parameters via console or PC GenWare®.

3 C.4.0 Generator Setup Menu

Explains functions and submenus in generator setup for configuration.

3 C.6.0 APR Editor

Describes enabling/disabling operator modification of APR techniques.

3 C.7.0 Generator Configuration

Covers configuration options: tube selection, limits, and I/O.

3 C.7.1 Tube Selection; Tube Setup

Selects X-ray tube type and configures default parameters and limits.

3 C.7.2 Generator Limits

Sets generator output limits for kW, mA, mAs, and rotor boost time.

3 C.7.3 Receptor Setup

Guides programming receptor settings: technique, AEC, and fields.

3 C.7.5 AEC Setup

Details programming Automatic Exposure Control (AEC) parameters.

3 C.13.2 APR Editor

Guides using APR editor to change, add, or delete APR techniques.

3 C.13.10 Touchscreen Console Firmware Upgrade; Restore

Guides upgrading or restoring touchscreen console firmware via USB or computer.

Chapter 4: Acceptance Testing

4.3.0 Acceptance Tests (Basic Functions)

Details tests for basic generator functions, console operations, and starter verification.

4.4.0 Acceptance Tests (kV, Time, mA and mAs)

Outlines tests for accuracy of kV, time, mA, and mAs output parameters.

4.5.0 Acceptance Tests (AEC)

Specifies tests for the Automatic Exposure Control (AEC) system.

4.8.0 Acceptance Tests (HVL, Linearity and Reproducibility)

Refers to a separate document for HVL, linearity, and reproducibility testing.

Chapter 5: Troubleshooting

5.2.0 Status and Error Codes

Lists and explains operator messages, limit messages, and error codes displayed by the generator.

5.3.0 Miscellaneous Faults

Addresses common faults like erratic console or frozen touchscreens and their solutions.

Chapter 6: Regular Maintenance

6.3.0 Maintenance Schedule

Details preventative maintenance tasks based on frequency (6 months, 12 months, 3 years, 5 years).

6.6.0 Firmware Upgrade

Covers upgrading firmware on console, generator, and dual speed starter EPROMs.

6.6.4 Resetting Factory Defaults

Explains resetting CPU to factory defaults and re-calibrating the tube.

Chapter 7: Theory of Operation

7.2.4 X-ray Exposure (MD-0931)

Explains process of initiating and controlling X-ray exposure, including prep signals.

7.2.5 kV Control and Feedback (MD-0932)

Details kV control loop, feedback mechanisms, and error handling for kV output.

7.2.6 Filament Drive and mA Control (MD-0934)

Explains filament current and mA control, including feedback and fault detection.

7.2.7 Dual-speed Starter (MD-0924)

Describes dual-speed starter operation, capacitor selection, and DIP switch settings.

7.2.12 AEC (MD-0936)

Explains AEC system operation, chamber signals, and processing.

Chapter 8: Spares

8.2.0 Spare Parts List

Provides a matrix listing recommended spare parts for CMP 200®/DR generator families.
