AR2700 & AR2700M SERIES
2
2
3
4
5-7
8-12
13-16
Specifications
Introduction
General Safety Instructions
Unit Preparation
Operation / Pump Down Operation
Maintenance
Parts List
17-18
AR2700 & AR2700M Specifications
Table Of Contents
Models
AR2700
AR2700M
AR2700A
AR2700MA
AR2700E
AR2700ME
Compressor Type 2/3 HP oil less compressor
Dimensions 22" W x 24.5" D x 42" H
Weight 120 lbs (does not include tank weight)
Operating Range 0˚C (32˚ F) to 49˚C (120˚)
Power Source
115 VAC
60Hz 1Ph
220-240VAC
50/60Hz 1Ph
Power Consumption 850 W
Suction Pressure Gauge -30 inch Hg to 125 PSIG
Discharge Pressure Gauge 0 to 500 PSIG
Filtration 16 cubic inch drier w/ moisture indicator, .7 micron oil separator
Manual Control Valves Ball Type Valves to control HI, LO, Recover, and Vacuum
Charging Valve 12 VDC Solenoid Valve
Construction
1" Heavy duty tubular frame construction
10" pneumatic wheels, 4.5" swivel casters
Overload Protection 15A Thermal Breaker 10A Thermal Breaker
High Pressure Shut-Off 30 bar (450 psig)
Refrigerants*
R134a, R12, R22, R502, R404a, R402a, R401a, R407c, R409a
* The AR2700, AR2700A, AR2700E does not contain a pump down valve and is meant for single
refrigerant operation. The AR2700M, AR2700MJ, AR2700ME contains a pump down valve for
mutiple refrigerant usage. Mixing of refrigerants will cause the user economic loss.
