OPERATION
8
To A/C System Being Serviced From Air Conditioning System Being Serviced
Optional Cylinder
Overfill Switch
LB
KG
TARE
DIAGRAM 1 (DIRECT VAPOR OR LIQUID RECOVERY)
Refrigerant Manifold Set
From Outlet Port Of
Recovery Machine
To Recovery Cylinder
TR700 Series
Refrigerant
Recovery
Machine
IN
To Inlet Port of
Recovery Unit
To Inlet Port of Recovery Machine
Recovery Cylinder
High Capacity Charging Scale
Optional Cylinder Overfill Sensor Cord
OUT
