CPS FX1234 - Specifications; Unit Specifications

Table of Contents
Specications 2
General Safety 3
Icon Library 4-5
First Time Start Up 6
Theory of Operation 7-8
Other Functions 9
Maintenance and Care 10-11
Parts List and Warranty 11
A/C Database End-User License Agreement 12-13
Unit Consists Of:
Specications
• FX1234 Automotive Refrigerant Management Center
• Low and High side service hoses R-1234yf
• Low and High side R1234yf Service Couplings
• Tank Rell Adapter-Fits High side female for R-1234yf tank thread
• R-1234yf conversion ttings for hose storage and oil ush block
• 41 cubic Inch CPS lter drier (Replacement part number FX3030X1)
• 1 lb (454 gram) check weight
• Operation manual
• 1 Roll 2.25” x 50” Thermal Paper (Printer not included with FX1234V)
• Built-in Refrigerant Identier
End user to provide:
• Refrigerant oil and/or dye for injection system
• Refrigerant
2
FX1234 Specications
Power 115vac. 60Hz, 15a; 10” 12 gauge power cord
Compressor 12.67 CC Twin Cylinder Oil-less
Vacuum Pump 6 CFM, single stage
Gauges 3.5” Low side, 30 in/Hg to 250 psi; High Side, 0 to 600 psi
Hoses 120” barrier type
Refrigerant R1234yf
Storage Tank 30lb DOT with Heat Band (Heat Band optional on FX1234V)
Display 7” Touch Screen with 256 color graphical display
Printer 22mm heat transfer graphical (Optional on FX1234)
Construction
Sheet metal frame adorned by injection and rotary molded plastic. Two handle bars, 4” front casters and 10” foam-lled rear tires for
exceptional maneuverability
