CPS FX1234 - Page 5

5
ICON LIBRARY
ICON NAME DESCRIPTION IMAGE
PLACE WEIGHT
Noties user to PLACE WEIGHT on the
scale
PRINT
Tap to PRINT a report of the service
PSIG
Tap to select PSIG
PT
Tap to select PRESSURE TRANSDUCER
PURITY
PURITY
QUIT
Tap to quit the current function
R1234yf
Tap to select R1234yf Refrigerant
R134a
Tap to select R134a Refrigerant
R22
Tap to select R22 Refrigerant
R407
Tap to select R407 Refrigerant
RECOVERY
Tap to perform an RECOVERY service
RECOVERY
COMPLETE
Indicates that the RECOVERY service is
COMPLETE
REFRIGERANT
REFRIGERANT
REFRIGERANT
CHANGE
Tap to CHANGE REFRIGERANT
REGISTER
Tap to REGISTER unit
RELAY
Tap to select RELAY
REMOVE WEIGHT
Noties user to REMOVE WEIGHT from
scale
SAE
Tap to select SAE
SAE CHARGE
Tap to perform a SAE CHARGE service
SAE CHARGE
COMPLETE
Indicates that the SAE CHARGE service
is COMPLETE
SCALE
Tap for SCALE functions
SCALE CHECK
Tap to perform SCALE CHECK
SCALE CHECK
The SCALE CHECK icon noties users
that a scale check is in progress
FULL
CALIBRATION
Tap to perform full calibration
SCALE ZERO
Tap to RE-ZERO the scale
SERVICE
Tap to select SERVICE
SERVICE HOSES
BEING FLUSHED
Indicates that the SERVICES HOSES are
BEING FLUSHED
ICON NAME DESCRIPTION IMAGE
SET TIME
Tap to SET TIME
SETTINGS
Tap to launch the SETTINGS screen
SETUP
Tap to launch the SEUP menu
SPEAKER
Tap to enable sound
START AC
Noties user to start vehicle and turn
on AC during service
TANK
Indicates the level of refrigerant in the
TANK
TANK FULL
Noties user that TANK is FULL
TANK HOSE
TANK REFILL
Tap to perform a TANK REFILL
Tank Tare Setup
Press to change tank weight and WC
TANKS REFILL
COMPLETE
Indicates that the TANK REFILL is
COMPLETE
TARE
Tap to select TARE
TURN UPSIDE
DOWN
Noties user to TURN TANK UPSIDE
DOWN during tank rell
UNIT
Tap to select UOM
UPDATE
Tap to UPDATE
UPGRADE
Tap to select UPGRADE
UPKEEP
Tap to launch the UPKEEP menu
VACUUM
Tap to perform a VACUUM service
VACUUM
COMPLETE
Indicates that the VACUUM service is
COMPLETE
VOLUME
Tap to Choose VOLUME UOM
WARNING
The WARNING icon appears to caution
users of a potential hazard
WEIGHT
Tap to Choose WEIGHT UOM
ZERO
Tap to RE-ZERO the pressure transducer
ZEROING
Indicates that the unit is ZEROING
