Table of Contents
Specifications 2
General Safety 3
Icon Library 4-5
First Time Start Up 6
Theory of Operation 7-8
Other Functions 9
Maintenance and Care 10-11
Parts List and Warranty 11
A/C Database End-User License Agreement 12-13
Unit Consists Of:
Specifications
• FX134a Automotive Refrigerant Management Center
• Low and High side service hoses R-134a
• Low and High side R134a Service Couplings
• Tank Refill Adapter-Fits High side female for R-134a tank thread
• R-134a fittings for hose storage and oil flush block
• 41 cubic Inch CPS filter drier (Replacement part number FX3030X1)
• Vent Temperature Probe
• 1 lb (454 gram) check weight
• SD Card with A/C Database
• Operation manual
• 1 Roll 2.25” x 50” Thermal Paper
End user to provide:
• Refrigerant oil and/or dye for injection system
• Refrigerant
2
FX134a Specifications
Power 115vac. 60Hz, 15a; 10’ 12 gauge power cord
Compressor 2/3 HP Twin Cylinder Oil-less
Vacuum Pump 6 CFM, single stage
Gauges 3.5” Low side, 30 in/Hg to 250 psi; High Side, 0 to 600 psi
Hoses 120” barrier type
Refrigerant R134a
Storage Tank 50 lb DOT with processor controlled heat band
Display 7” Touch Screen with 256 color graphical display
Printer 22mm heat transfer graphical
Construction
Sheet metal frame adorned by injection and rotary molded plastic. Two handle bars, 4” front casters and 10” foam-filled rear tires
for exceptional maneuverability
