USER MANUAL
20
113-168 M1 LIBRATING Mode 3
169-255 M1 LIBRATING Mode 4
6
ROT SPEED
000-255
M2 Rotating Speed
M2 Stands for Motor 1
7
ROT
DIRECTION
000-075
M2 Clockwise Rotation
076-150
M2 Stop
151-255
M2 Anti-clockwise Rotation
8
LIBRATE
RANGE
000-255
M2 Librating Range
9
LIBRATE
MODE
000-056 M2 LIBRATING Mode 1
057-112 M2 LIBRATING Mode 2
113-168 M2 LIBRATING Mode 3
169-255 M2 LIBRATING Mode 4
10
COLOR
000-028 Red & Green
NONE Function in
Channel 11
029-056 Green
057-084 Red
085-112 Red Off, Strobed Green
113-140 Green Off, Strobed Red
141-168 Red On, Strobed Green
169-197 Green On, Strobed Red
198-224 Both Red and Green Strobed
225-255 Alternately Strobed Red & Green
11
Strobe
000-255
Slow to Fast
