Cradlepoint AER1650 - Modem Status LEDs; Signal Strength; Modem Connection Status; Additional LED Indications

cradlepoint.com
5
SIGNAL STRENGTH Blue LED bars indicate the active modem’s signal strength.
• 4 Solid Bars = Strongest signal.
• 1 Blinking Bar = Weakest signal. (A blinking bar indicates half of a bar.)
INTERNAL MODEM Indicates the status of internal modems.
EXTERNAL USB MODEM Indicates the status of external USB modems.
All modems have the following LED indicators:
• Green = Modem has established an active connection.
• Blinking Green = Modem is connecting.
• Amber = Modem is not active.
• Blinking Amber = Data connection error. No modem connection possible.
• Blinking Red = Modem is in the process of resetting.
LEDS
ADDITIONAL LED INDICATIONS
• Several different LEDs flash when the factory reset button is detected.
• Two of the modem LEDs blink red in unison for 10 seconds when there is an error
during firmware upgrade.
EMBEDDED MODEM Indicates the status of embedded modem.
