Cradlepoint CBA750B - Ports, Buttons; Switches

CRADLEPOINT CBA750B | USER MANUAL Firmware version 5.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 13
2.1 Ports, Buttons, and Switches
130 mm
230 mm
LAN Port
Power On/Off
DC Power Port
LEFT SIDE
RIGHT SIDE
USB 2.0
ExpressCard Slot
ExpressCard Lock
Router/Passthrough
Switch
USB 2.0
Reset
Modem Signal
Strength
40 mm
LED STATUS INDICATORS
PoE
4G 3G 2G
