6
CX507 – 16" OPEN END DRUM SANDER
PHYSICAL FEATURES
Conveyor Belt
Tracking
Adjuster
Front Nip Guard
Feed Belt
Conveyor Belt
Feed Motor
Conveyor Belt
Speed Control
Knob
Dust Collection
Port elbow
Dust Cover
Handle & Latch
Sanding Drum
Dust Cover
Height Adjustment
Hand Wheel
Variable Speed
Control Box
Conveyor Feed
Belt
Magnetic
Switch
Sanding Drum
Motor
Height Gauge
Stand Mounting
Hole
Stand
