page 2
2. Parts Inventory.
a. canopy. 1 piece
b. hanging bracket. 1 piece
c. 4½in. downrod and hanging ball. 1 piece
d. remote control receiver. 1 piece
e. wall control and plate. 2 separate pieces
f. remote control transmitter. 1 piece
g. canopy cover (in hardware pack or
pre-attached to canopy). 1 piece
h. safety cable (already attached to motor).
1 piece
i. motor assembly. 1 piece
j. yoke cover. 1 piece
k. hardware packs
a
1. Unpacking Your Fan.
Carefully open the packaging. Remove items
from Styrofoam inserts. Remove motor assembly
and place on carpet or Styrofoam to avoid
damage to finish. Do not discard fan carton or
Styrofoam inserts should this fan need to be
returned for repairs.
Check against parts inventory that all parts have
been included.
IMPORTANT REMINDER: You must
use the parts provided with this fan for
proper installation and safety.
e
b
c
d
i
h
g
k
f
w/ remote
w/ wall
control
j
