a. hanging bracket. 1 piece
b. canopy. 1 piece
c. downrod and hanging ball
(with pin & clip). 1 piece
d. yoke cover. 1 piece
e. motor housing. 1 piece
f. light kit fitter (already attached to motor).
1 piece
g. blade plate. 5 pieces
h. blade. 5 pieces
i. glass shade. 1 piece
j. hardware packs
page 2
2. Parts Inventory.
1. Unpacking Your Fan.
Carefully open the packaging. Remove items
from Styrofoam inserts. Remove motor housing
and place on carpet or Styrofoam to avoid
damage to finish. Do not discard fan carton or
Styrofoam inserts should this fan need to be
returned for repairs.
Check against parts inventory that all parts have
been included.
IMPORTANT REMINDER: You must
use the parts provided with this fan for
proper installation and safety.
required bulbs:
2 x 40 watt max. candelabra base bulbs,
(included)
h
i
e
a
b
c
f
g
d
j
