Craftsman 220 - Section 2: Trailer PARTS & Hardware; Parts List

11
PARTS LIST
ID Description Qty
AA Gate/Ramp 2
AB Hand Crank 1
AC 2” x 4” Distance Indicator (Do Not Discard) 1
AD Locking Pin w/ Lanyard (Connected) 1
AE Cotter Key (Connected) 1
TOOLS NEEDED (NOT INCLUDED)
1. 13/16” Lug Wrench or Tire Iron (For changing Tires and periodic tightening of Lug
Nuts).
SECTION 2: TRAILER PARTS &
HARDWARE
HARDWARE IDENTIFIER
(*Not to Scale)
*AA
*AC
*AB
*AD
*AE
Before beginning assembly, inventory all parts using the Parts List and the Hard-
ware Identier (below). If all parts are not present, do NOT assemble the trailer.
Call 1-800-422-3865.
Do Not Discard
