16
4.7 Remove the Cotter Key (AE) from the Locking Pin (AD) and insert the Locking
Pin into the Bed Pin Retainer and through the Tongue.
4.8 Secure the Locking Pin (AD) in place with the Cotter Key (AE).
CAUTION
ALWAYS tow the Trailer with Locking Pin and Cotter Key in place
through Trailer bed and Tongue. Ensure you remove Cotter Key and
Locking Pin when folding Trailer.
AE
AD
Note: If the holes in the Bed Pin Retainer and Tongue do not align, you must fully
unfold the trailer.
