10
Fresh Start® Fuel Cap
The Fresh Start® fuel cap (A) is designed to hold a
cartridge (B) which contains fuel preserver. Adding fuel
preserver helps keep fuel fresh and carburetors clean for
easier starting all season long. The Fresh Start® fuel cap, if
equipped with a cartridge, automatically drips concentrated
fuel preserver into your fuel tank so you don’t have to add it
yourself.
NOTICE Purchase a Fresh Start® fuel preserver cartridge,
Sears item 33386, at your local Sears or by calling 1-800-4-
MY-HOME (469-4663) or online at www.sears.com. It is not
included with the pressure washer.
Read and follow all instructions and warnings given in the
Fresh Start® fuel preserver cartridge package.
Lubricate O-Rings
Lubrication of o-rings is extremely important for installation
and operation. The use of a lubricant (petroleum or synthetic
grease) during assembly helps seat o-rings properly and
provides an improved seal. It also helps protect the o-ring
from damage by abrasion, pinching or cutting and extends
the life of the o-ring.
NOTICE ALWAYS apply a small amount of lubricant on
o-rings prior to assembling the garden hose to the pump (C),
high pressure hose (D), spray gun (E), and nozzle
extension (F).
Lubricate all connections shown below, following these
instructions:
1. Inspect and clean connecting surfaces prior to
lubrication and assembly.
2. Use lubricants sparingly during assembly; a light film is
all that is required.
3. Use a small brush or cotton swab to apply grease
directly to o-rings where they are not accessible (QC
fitting, M22 fitting).
A
B
F
E
C
D
