31
Item Part # Description
1 798948 Cylinder Assembly
3 299819s Seal-Oil (Magneto Side)
4 493279 Sump-Engine
5 796471 Head-Cylinder
7 796475 Gasket-Cylinder Head
11 796478 Tube-Breather
12 692232 Gasket-Crankcase
13 796451 Screw (Cylinder Head)
15 691680 Plug-Oil Drain
16 799337 Crankshaft
20 399781s Seal-Oil (PTO Side)
22 691092 Screw (Crankcase Cover/Sump)
23 796621 Flywheel
24 222698s Key-Flywheel
25 796643 Piston Assembly (Standard)
796644 Piston Assembly (.020” Oversize)
26 796645 Ring Set (Standard)
796646 Ring Set (.020” Oversize)
27 691588 Lock-Piston Pin
28 298909 Pin-Piston
29 796470 Rod-Connecting
32 691664 Screw (Connecting Rod) (1/4-20x1.09)
32A 695759 Screw (Connecting Rod) (1/4-20x1.5)
33 499642 Valve-Exhaust
34 795443 Valve-Intake
35 691304 Spring-Valve (Intake)
36 691304 Spring-Valve (Exhaust)
37 796536 Guard-Flywheel (Carburetor Side)
37A 799155 Guard-Flywheel
40 692194 Retainer-Valve
43 796651 Slinger-Governor/Oil
45 690977 Tappet-Valve
46 694039 Camshaft
51 796596 Gasket-Intake
58 791362 Rope-Starter (Cut to Required Length)
60 281434s Grip-Starter Rope
78 793480 Screw (Flywheel Guard)
81 691740 Lock-Muffler Screw
89 692348 Plug-Oil (Cylinder)
98 797156 Kit-Idle Speed
104 797622 Pin-Float Hinge
118 799605 Main Jet (High Altitude)
121 796612 Kit-Carburetor Overhaul
122 796595 Spacer-Carburetor
125 799248 Carburetor
127 694468 Plug-Welch
130 797630 Valve-Throttle
133 797626 Float-Carburetor
134 799177 Kit-Needle/Seat
137 797625 Gasket-Float Bowl
163 691894 Gasket-Air Cleaner
187 791766 Line-Fuel (Cut to Required Length)
190 793479 Screw (Fuel Tank)
192 796631 Adjuster-Rocker Arm
202 796631 Link-Mechanical Governor
209 793604 Spring-Governor (Purple)
216 798944 Link-Choke
216A 796485 Link-Choke
217 799179 Spring-Choke Return
222 796482 Bracket-Control
227 796487 Lever-Governor Control
238 691300 Cap-Valve
276 797632 Washer-Sealing
287 793479 Screw (Dipstick Tube)
291 798938 Thermostat
300 798940 Muffler
304 796692 Housing-Blower
332 690662 Nut (Flywheel)
Item Part # Description
333 796500 Armature-Magneto
334 793454 Screw (Magneto Armature)
334A 796537 Stud (Magneto Armature)
337 692051 Plug-Spark
347 798939 Switch-Rocker
356 798942 Wire-Stop
356A 798943 Wire-Stop
358 796661 Gasket Set-Engine
365 793458 Screw (Carburetor)
404 690272 Washer (Governor Crank)
455 796615 Cup-Flywheel
505 793515 Nut (Governor Control Lever)
523 796503 Dipstick
524 692296 Seal-Dipstick Tube
525 796502 Tube-Dipstick
534 798294 Screw (Air Cleaner)
535 797301 Filter-Air Cleaner Foam
536 799025 Cleaner-Air
562 793514 Bolt (Governor Control Lever)
564 690351 Screw (Control Cover) (10-32x.50)
564A 799026 Screw (Control Cover) (#8-18x.90)
592 793481 Nut (Rewind Starter)
601 791850 Clamp-Hose (Green)
604 799024 Cover-Control
608 796497 Starter-Rewind
613 796496 Screw (Muffler)
615 796674 Retainer-Governor Shaft
616 796488 Crank-Governor
621 692310 Switch-Stop (Control Bracket)
623 793628 Seal-O Ring (Carburetor Spacer)
633 797629 Seal-Choke/Throttle Shaft (Throttle Shaft)
633A 797629 Seal-Choke/Throttle Shaft (Choke Shaft)
635 66538s Boot-Spark Plug
670 793485 Spacer-Fuel Tank
718 690959 Pin-Locating
741 797521 Gear-Timing
830 796472 Stud-Rocker Arm
832 798951 Guard-Muffler
836 793500 Screw (Muffler Guard)
842 691031 Seal-O Ring (Dipstick Tube)
847 796501 Dipstick/Tube Assembly
851 493880s Terminal-Spark Plug
868 795440 Seal-Valve
883 793497 Gasket-Exhaust
883A 796677 Gasket-Exhaust
886 796474 Gasket Kit-Cylinder Head Plate
914 794451 Screw (Rocker Cover)
925 796531 Cover-Linkage
950 797575 Screw-Float Bowl (Includes Main Jet)
957 799585 Cap-Fuel Tank (Short)
957 796577 Cap-Fuel Tank (Tall)
972 590949 Tank-Fuel (Internal Threads) (w/Short Cap)
972 796489 Tank-Fuel (External Threads) (w/Tall Cap)
975 797631 Bowl-Float
993 796473 Gasket-Cylinder Head Plate
1005 796614 Fan-Flywheel
1022 796480 Gasket-Rocker Cover
1023 796479 Cover-Rocker
1026 796481 Rod-Push
1029 691230 Arm-Rocker
1034 691343 Guide-Push Rod
1059 793471 Kit-Screw/Washer (Fuel Tank)
1095 796662 Gasket Set-Valve
1263 697124 Reed-Breather
1264 793453 Screw (Breather Reed)
1375 796476 Cover-Breather/Reed
1376 794451 Screw (Breather/Reed Cover)
1430 796477 Gasket-Breather/Reed
ENGINE, Briggs & Stratton, 111P02 – Parts List
