Craftsman 65018 - Shed Wall Assembly - Initial Steps; Installing Left Front Corner Panel

13
Critical: When installing corners,
flex corner hinges back and forth
several times. This will help provide
a square corner and ensure proper
fit of remaining panels.
Important: DO NOT flex in reverse
position, as this can crack the panel.
SHED ASSEMBLY – WALLS
7
Align tab on bottom right side of left front corner (D)
with slot on floor (S). Lower panel into slot and lock in
place by sliding panel toward door opening. Note: Use
a rubber mallet to “push” left front corner (D) into
locked position.
Tip left front corner (D) outward slightly and bend the
corner hinge.
1
2
D
S
8
1
22
D
9
