Craftsman 65018 - Shed Roof Supports and Door Hinge Prep; Preparing Door Hinges for Mounting

22
11
2
x3
33
M
Stand right door (M) upright with three hinge mounts
facing right. Slide one metal hinge plate (V) up onto each
hinge mount. Rotate hinge plates to outside of door.
Repeat for left door (N).
Rotate metal hinge plates to open position. Slide one
metal hinge plate over each hinge receptacle on inside
of right front panel. Note: For clarity, illustration is shown
with roof and ridge beam removed.
2
x3
32
V
M
x3
Secure front roof support bracket (HH) to underside
of roof using two screws (BB). Repeat step 31 for
remaining roof support bracket.
31
BB
HH
x6x2
Shed Assembly/Doors
Shed Assembly – Roof/Continued
