Craftsman C459-60116 User Manual

Ref. No. Part No. Description
868 690968 Seal-Valve
883 690970 Gasket-Exhaust
914 691127 Screw (Rocker Cover)
918 797408 Hose-Vacuum (Rocker Cover)
918A 799160 Hose-Vacuum (EVAP System)
929 695239 Screw (Choke Control Bracket)
943 796222 Seal-O Ring (Oil Pump Cover)
947 798779 Solenoid-Fuel
964 799159 Cap-Connector
965 796221 Cover-Oil Pump
967 792303 Filter-Pre Cleaner
968 795120 Cover-Air Cleaner
975 798778 Bowl-Float
987 691000 Seal-Throttle Shaft
1005 791236 Fan-Flywheel
1013 690954 Nipple-Oil Filter
1017 796214 Screen-Oil Pump
1022 690971 Gasket-Rocker Cover
1023 793146 Cover-Rocker (Cylinder #1)
1023A 499600 Cover-Rocker (Cylinder #2)
1024 796220 Pump-Oil
1026 690981 Rod-Push (Exhaust) (Steel)
1026A
690982
Rod-Push (Intake) (Aluminum)
1027 795890 Filter-Oil
1029 690972 Arm-Rocker
1036
Label-Emissions (Available from a Briggs
& Stratton Authorized Dealer)
1040 791237 Plate-Trim
1051 691265 Ring-Retaining (Starter Drive)
1054 280275 Tie-Cable
1058 278776TRI Operator's Manual
1059 698516 Kit-Screw/Washer (Alternator)
1070 791680 Screw (Flywheel Fan)
1090 691293 Retainer-Brush
1095 694013 Gasket Set-Valve
1100 791959 Pivot-Rocker Arm
1119 691183 Screw (Alternator)
1124 841653 Seal-O Ring (Fuel Transfer Tube)
1124A 690988 Seal-O Ring (Fuel Transfer Tube)
1126 690991 Screw (Fuel Transfer Tube)
Ref. No. Part No. Description
1127 695407 Screw (Fuel Bowl)
1128 690990 Screw (Carburetor Nozzle)
1169 690990 Screw (Carburetor Plate)
1329
44P777-
2799-G1
Replacement Engine
1330 273521 Repair Manual
Key No. 358
Engine Gasket Set
Key No. 1095
Valve Gasket Set
Key No. 121
Carburetor Overhaul Kit
Craftsman Engine Model 44P777-2799-G1 For Model C459-60116
PARTS LIST
56
