7
ENGLISH
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of
serious personal injury, turn unit off and
disconnect it from power source before making
any adjustments or removing/installing
attachments or accessories. An accidental start-up
can causeinjury.
Attaching Vacuum Hose (Fig. A, B)
The vacuum hose
8
will need to be attached to the
vacuum before using the appliance.
1. Place the vacuum on a flat, firmsurface.
2. Unlatch tank latches
5
and remove power head from
the tank. Remove the vacuum hose
8
from the tank
4
.
3. Align the hose end
13
with the intake port
6
on the
front of the appliance, ensuring the hose alignment lock
14
is aligned with the arrow
15
on the intake port.
4. Insert the hose end into the intake port and twist
clockwise to lock in place.
5. Replace power head onto the tank and secure latches.
NOTE: The power head will only fit onto the tank when the
intake port on the front of the power head and the storage
area for the wide nozzle tool
12
on the tank are aligned.
Fig.B
14
13
15
OPERATION
WARNING: To reduce the risk of
serious personal injury, turn unit off and
disconnect it from power source before making
any adjustments or removing/installing
attachments or accessories. An accidental can
causeinjury.
Installing and Removing the Battery Pack
(Fig. C)
CAUTION: Ensure battery port and
terminals are dry and clean before installing
batterypack.
To install the battery pack
16
into the power head, align
the battery pack with the rails inside the tool’s battery port
7
until the battery pack is firmly seated in the tool and
ensure that it does notdisengage.
To remove the battery pack from the tool, press the release
button
17
and firmly pull the battery pack out of the tool
handle. Insert it into the charger as described in the charger
section of thismanual.
Fig.C
7
16
17
Using the Vacuum
On / Off Switch (Fig. A, D)
1. Attach the appropriate accessory to the vacuum hose
8
.
2. Insert battery pack.
3. To turn vacuum on, press the I/O (on/off) button
1
.
COMPONENTS (FIG. A)
Intended Use
The vacuum is designed to perform as a wet/dry unit
with no component changes required when changing
from wet to dry, or dry to wet pick up. This vacuum is for
household use only.
It is recommended that the tank be emptied of any dry
contents prior to being used for wet pick up to facilitate
tank cleaning.
DO NOT use under wet conditions or in presence of
flammable liquids orgases.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
