1
ENGLISH
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or property damage.
DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in .
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in .
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in .
(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in
.
Hot Surfaces Compressor PumpFig. A
WARNING: Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
WARNING: Never modify the product or any part of
it. Damage or personal injury could result.
WARNING: To reduce the risk of injury, read the
instruction manual.
If you have any questions or comments about this
or any product, call CRAFTSMAN toll free at:
1-888-331-4569
Components
Auto/Off Switch
Pressure Switch (not shown)
Safety Valve
Tank Pressure Gauge
Check Valve
Air Intake Filter
Air Compressor Pump
Drain Valve
Air Outlet
Motor Overload Protector
Compressor Pump Head
Compressor Pump Cylinder
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
Outlet Tube
Oil Fill Plug
Oil Sight Glass
Oil Drain Plug
Regulated Pressure Gauge
Regulator
Grounded Outlet
Plug
Grounding Pin
14
15
16
8
7
6
10
9
4
1
3
18
17
2
5
20
21
19
12
11
13
CAUTION

Craftsman CMXECXM301 Specifications

General

Brand	Craftsman
Model	CMXECXM301
Category	Air Compressor
Language	English
