9
ENGLISH
necessary to pick up dust. If the cartridge filter
is wet, it will clog quickly and be very difficult
to clean. Handle the filter carefully when
removing it for cleaning and replacing it. Check
the filters for tears or small holes. A small hole
can let dust pass through and out of the filter.
Do not use a filter with holes or tears; replace
it immediately.
INSTALLING AND CLEANING THE
CARTRIDGE FILTER:
WARNING:
VERIFY THAT THE
POWER CORD IS DISCONNECTED FROM THE
OUTLET.
22. Remove the power head and place in an
upside-down position.
23. Install the cartridge filter
25
over the filter
cage making sure the cage is completely
covered. Fig. 14.
Fig. 14
24. Place the filter retainer
24
on the top of
the cartridge filter
25
over the raised lip
and tighten down by turning the retainer
clockwise; do not over-tighten.
Fig. 15 & 16.
Fig. 17
Fig. 18
25. To remove the cartridge filter, unlock and
remove the filter retainer
24
by turning the
retainer handle counter-clockwise.
Fig. 17 & 18.
26. With the removed power head in an
upside-down position, carefully remove
the cartridge filter
25
from the filter cage.
Fig. 19.
Fig. 15
Fig. 16
