Craftsman CMXGTAMDZ22C User Manual

48 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

769-23110 / 00 08/19

2-CYCLE GAS TRIMMERS

DESBROZADORAS DE GAS DE 2 TIEMPOS

OPERATOR’S MANUAL | MANUAL DEL OPERADOR

WC215 | WS215

CMXGTAMDZ20C | CMXGTAMDZ22C

1-888-331-4569 WWW.CRAFTSMAN.COM

IF YOU HAVE QUESTIONS OR COMMENTS, CONTACT US.

SI TIENE DUDAS O COMENTARIOS, CONTÁCTENOS.

Questions and Answers:

D
Danielle PalmerAug 8, 2025
How to start a Craftsman CMXGTAMDZ22C Trimmer if it won't start?
- G
  Gina ThompsonAug 8, 2025
  If your Craftsman Trimmer engine won't start, there are several possible causes: * The fuel tank may be empty, in which case you should fill it with properly-mixed fuel. * You may not have pressed the primer bulb enough; try pressing it 10 times. * The engine might be flooded; press the throttle lockout, squeeze the throttle control, and pull the starter rope until the engine starts. * The fuel could be old (over 30 days) or improperly mixed; drain the tank and add fresh, properly-mixed fuel. * The spark plug might be fouled, requiring replacement. * The choke lever may not have been flipped. Refer to the Starting Instructions in the Starting and Stopping section.
L
Lauren ThomasAug 13, 2025
Why does my Craftsman Trimmer engine lack power or stall?
- J
  Justin JonesAug 13, 2025
  If your Craftsman Trimmer engine lacks power or stalls, it could be due to several reasons. The fuel might be old (over 30 days) or improperly mixed, in which case you should drain the fuel tank and add fresh, properly-mixed fuel. Another possibility is a dirty air filter, which requires cleaning or replacement. Lastly, a fouled spark plug can also cause this issue, so consider replacing it.
T
Tiffany RuizAug 18, 2025
Why won't my Craftsman CMXGTAMDZ22C Trimmer engine idle?
- S
  Scott FreemanAug 18, 2025
  If your Craftsman Trimmer engine will not idle, there are a few potential causes. The air filter may be dirty, so you should clean or replace it. The fuel might be old (over 30 days) or improperly mixed; in this case, drain the fuel tank and add fresh, properly-mixed fuel. Additionally, the idle speed could be incorrect, requiring adjustment.
K
Karen FlowersAug 23, 2025
What to do if the cutting line advances uncontrollably on my Craftsman CMXGTAMDZ22C?
- C
  carlwongAug 23, 2025
  If the cutting line on your Craftsman Trimmer advances uncontrollably, it's likely due to oil, cleaner, or lubricant being present in the cutting head. To resolve this, clean the cutting head thoroughly.
M
Mark HudsonAug 28, 2025
Why won't the cutting head advance line on my Craftsman CMXGTAMDZ22C?
- P
  Penny DurhamAug 28, 2025
  If the cutting head on your Craftsman Trimmer will not advance line, several issues could be the cause. The cutting head might be bound with grass, so stop the engine and clean it. The cutting head could be out of line, requiring you to refill it with new line. The inner reel might be bound up, so clean the inner reel and outer spool. The cutting head may be dirty, so open it and remove any welded sections. The line could be welded, in which case you should rewind it. The line might be twisted; stop the unit, push the bump knob, and pull the line until 4 inches (102 mm) extends outside the cutting head. Finally, not enough line might be extended, so clean and thoroughly dry the cutting head.
C
Carla FloresSep 1, 2025
What to do if my Craftsman Trimmer engine will not accelerate?
- A
  Anita ShieldsSep 2, 2025
  If your Craftsman Trimmer engine will not accelerate, it could be due to old or improperly mixed fuel (over 30 days old). Drain the fuel tank and add fresh, properly-mixed fuel. Another cause could be the cutting head being bound with grass; stop the engine and clean the cutting head. A dirty air filter can also prevent acceleration, so clean or replace it.

Craftsman CMXGTAMDZ22C Specifications

General

Brand	Craftsman
Model	CMXGTAMDZ22C
Category	Trimmer
Language	English

Summary

Important Safety Instructions

Safety Warnings for Gas Units

Assembly

Installing Cutting Head Shield WC215

Instructions for attaching the cutting head shield to the WC215 model, ensuring safety.

Installing Cutting Head Shield WS215

Instructions for attaching the cutting head shield to the WS215 model, ensuring safety.

Oil and Fuel Mixing Instructions

Mixing the Fuel

Instructs on the correct procedure and ratio for mixing fuel and oil for the unit.

Fueling the Unit

Starting and Stopping

Starting Instructions

Step-by-step guide on how to properly start the trimmer engine.

Stopping Instructions

Instructions for safely shutting down the trimmer engine.

Operation

Holding the Unit

Adjusting Trimming Line Length

Details how to extend the trimmer line using the bump head mechanism.

Maintenance

Maintenance Schedule

Outlines the recommended maintenance tasks and their frequencies.

Replacing the Trimming Line

Step-by-step guide for installing new trimmer line into the cutting head.

Adjusting the Idle Speed

Maintaining the Spark Plug

Cleaning and Storage

Cleaning the Unit

Troubleshooting

Warranty
