Sears Brands Management Corporation, Hoffman Estates, IL 60179, U.S.A.
Visit our website: www.craftsman.com
CAUTION: Before using this
product, read this manual and
follow all safety rules and operating
instructions.
Operator’s Manual
• SAFETY
• ASSEMB LY
• OPERATION
• MAINTENANCE
• PARTSLIST
• ESPAÑOL
33” LAWN MOWER
Model No. 247.374880
Form No. 769-08683
(December 10, 2012)
