Craftsman Sears 900 Series User Manual (English)

Questions and Answers:

C
Carrie HughesAug 17, 2025
How to fix a Craftsman Sears 900 Tiller that will not start?
- K
  kayla91Aug 17, 2025
  If your Craftsman Tiller won't start, there are several potential causes. First, ensure that the fuel tank is filled with gasoline. If the engine is not choked properly, refer to the “TO START ENGINE” section in the Operation section. If the engine is flooded, wait a few minutes before trying again. Other possible causes include a dirty air cleaner (clean or replace it), water in the fuel (drain and refill with fresh gasoline), a clogged fuel tank (remove and clean it), a loose spark plug wire (ensure it's properly seated), a bad spark plug or improper gap (replace or adjust it), a misadjusted carburetor (adjust as needed), or a closed fuel shut-off valve (open the valve).
C
Cathy DeanAug 22, 2025
Why is my Craftsman Sears 900 Tiller hard to start?
- J
  Jennifer GregoryAug 22, 2025
  If your Craftsman Tiller is hard to start, begin by ensuring the throttle control is in the “FAST” position. A dirty air cleaner can also cause starting issues, so clean or replace the air cleaner cartridge. Check the spark plug for damage or improper gap, and replace or adjust as needed. Stale or dirty fuel may be the culprit; drain the fuel tank and refill with fresh gasoline. Also, make sure the spark plug wire is securely connected. Finally, the carburetor may need adjustment.
R
Russell MartinezAug 25, 2025
What to do if my Craftsman Tiller engine overheats?
- J
  Jeffrey HallAug 26, 2025
  If your Craftsman Tiller engine overheats, start by checking the oil level and condition; replenish or change the oil as needed. Next, inspect the engine air screen and clean it if it's dirty. A dirty engine can also cause overheating, so clean the cylinder fins, air screen, and muffler area. If the muffler is partially plugged, remove and clean it. Finally, the carburetor adjustment may be improper, so adjust the carburetor to a richer position.
C
Cody CastilloAug 27, 2025
Why does my Craftsman Tiller run but won’t move?
- S
  Sarah BrownAug 27, 2025
  If your Craftsman Tiller runs, but the tines won’t move, first ensure that the drive control bar is engaged. If it is engaged and the tines still aren't moving, inspect and adjust the V-belt. Also, check to see if the V-belt is off the pulley(s).
E
Elizabeth SullivanAug 30, 2025
Why does my Craftsman Sears 900 Tiller shut off when drive control bar is engaged?
- V
  virginia68Aug 30, 2025
  If the Craftsman Tiller shuts off when the drive control bar is engaged, it might be due to the shift lever being set in between the counter rotating till position and the forward rotating till position. Shift to either the counter rotating till position or the forward rotating till position. Another potential cause is jammed tines, so clear the tines.
D
Daniel JohnsonSep 2, 2025
Why does my Craftsman Tiller engine run but labors when tilling?
- A
  Andrea YoungSep 2, 2025
  If your Craftsman Tiller engine runs but labors when tilling, it could be due to tilling too deep. Adjust the depth stake for shallower tilling. Also, check the throttle control setting to ensure it is properly adjusted. If these steps don't resolve the issue, the carburetor may be out of adjustment and require necessary adjustments.
Z
zharveySep 5, 2025
Why is my Craftsman Tiller experiencing excessive bounce or difficult handling?
- L
  Lori PriceSep 5, 2025
  If your Craftsman Tiller is experiencing excessive bounce or difficult handling, it may be due to the ground being too dry and hard. Moisten the ground or wait for more favorable soil conditions.
K
Karen WoodwardSep 7, 2025
Why does soil ball up or clump when using my Craftsman Sears 900 Tiller?
- E
  Elizabeth HarrellSep 7, 2025
  If the soil balls up or clumps when using your Craftsman Tiller, it is likely because the ground is too wet. Wait for more favorable soil conditions.
J
Justin BradySep 12, 2025
Why do the tines skip over the ground on my Craftsman Sears 900 Tiller?
- J
  Justin ShortSep 12, 2025
  If the tines on your Craftsman Tiller skip over the ground, ensure that the drag stake is lowered when in forward rotating till mode. Lower the drag stake to resolve this issue.

Craftsman Sears 900 Series Specifications

General

Tilling Width	18 inches
Number of Tines	4
Forward Speeds	1
Reverse Speeds	1
Engine Type	4-cycle

Summary

SAFETY RULES

SAFE OPERATION PRACTICES

Safe operation guidelines for walk-behind powered rotary tillers.

TRAINING

Proper user training and familiarization with controls before operation.

PREPARATION

Steps to prepare the tiller and the work area before operation.

OPERATION SAFETY

Key safety precautions during tiller operation.

MAINTENANCE AND STORAGE

Guidelines for maintaining and storing the tiller.

PRODUCT SPECIFICATIONS

CUSTOMER RESPONSIBILITIES

ASSEMBLY

TOOLS AND HARDWARE

Lists tools required and hardware included for tiller assembly.

OPERATOR'S POSITION

Defines operator's perspective for directional references in the manual.

UNPACKING CARTON

Instructions for safely unpacking the tiller from its shipping carton.

INSTALL HANDLE

Step-by-step guide for attaching the tiller's handle assembly.

CABLE AND SHIFT ROD CONNECTION

Procedures for connecting control cables and the shift rod.

CRATE REMOVAL AND FINAL CHECKS

Steps to remove the tiller from the crate and conduct final assembly checks.

OPERATION

KNOW YOUR TILLER

Familiarization with tiller controls, adjustments, and safety symbols.

HOW TO USE YOUR TILLER

Detailed guide on operating tiller controls and functions.

TILLING AND CULTIVATING TECHNIQUES

Methods for tilling, cultivating, and adjusting depth/drag stakes.

GEAR SHIFTING AND TURNING

Procedures for shifting gears and turning the tiller.

TRANSPORTING AND PRE-START CHECKS

Guidelines for transporting the tiller and checking engine oil before starting.

ADDING FUEL AND STARTING THE ENGINE

Instructions for adding gasoline and starting the tiller's engine.

TILLING HINTS

Tips for effective tilling based on soil conditions and technique.

TINE SHEAR PINS

Information on the function and replacement of tine shear pins.

MAINTENANCE

MAINTENANCE SCHEDULE

A schedule for routine maintenance tasks based on usage hours or time.

GENERAL RECOMMENDATIONS

General advice for maintaining the tiller and its warranty.

LUBRICATION CHART

Visual guide indicating lubrication points and types of lubricants.

ENGINE MAINTENANCE

Procedures for maintaining the tiller's engine, including oil and air cleaner.

LUBRICATION AND OIL CHANGE

Details on engine oil types, checking levels, and changing oil.

AIR CLEANER CARE

Instructions for cleaning or replacing the air cleaner cartridge.

COOLING, MUFFLER, AND SPARK PLUG

Maintenance for cooling system, muffler, and spark plug replacement.

TRANSMISSION AND CLEANING

Lubrication for the transmission and general cleaning procedures.

SERVICE AND ADJUSTMENTS

TILLER ADJUSTMENTS AND REPAIRS

Adjustments and repairs related to the tiller's physical components.

HANDLE HEIGHT AND TIRE CARE

Adjusting handle height and maintaining tire pressure and condition.

BELT GUARD AND DRIVE BELT

Procedures for removing belt guard and replacing ground drive belt.

GROUND DRIVE BELT ADJUSTMENT

How to adjust the tension of the ground drive belt.

TINE REPLACEMENT

Guidelines for checking and replacing tiller tines.

ENGINE CONTROLS ADJUSTMENT

Adjusting throttle control cable and carburetor settings.

STORAGE

TILLER PREPARATION FOR STORAGE

Steps for cleaning, lubricating, and securing the tiller for storage.

ENGINE STORAGE PROCEDURES

Guidelines for storing the engine, including fuel system and cylinder care.

TROUBLESHOOTING POINTS

ENGINE STARTING AND POWER ISSUES

Diagnosing and resolving problems like engine not starting or loss of power.

OPERATIONAL AND HANDLING PROBLEMS

Troubleshooting issues such as overheating, bouncing, or shifting difficulties.

REPAIR PARTS

HANDLES ASSEMBLY

Exploded view and part numbers for the tiller's handle assembly.

MAINFRAME, LEFT SIDE

Exploded view and part numbers for the left side mainframe components.

MAINFRAME, RIGHT SIDE

Exploded view and part numbers for the right side mainframe components.

TRANSMISSION COMPONENTS

Exploded view and part numbers for the tiller's transmission assembly.

TINE SHIELD AND RELATED PARTS

Exploded view and part numbers for the tine shield assembly.

TINE ASSEMBLY COMPONENTS

Exploded view and part numbers for the tiller's tine assemblies.

DECALS AND MANUALS

Part numbers for decals and owner's manuals.

ENGINE COMPONENTS (Page 28)

Exploded view and part numbers for the Briggs & Stratton engine components.

ENGINE COMPONENTS (Page 29)

Detailed exploded views of engine parts like the carburetor and fuel tank.

ENGINE COMPONENTS (Page 30)

Exploded views of various engine components like starter and ignition parts.

ENGINE COMPONENTS (Page 31)

Exploded views of engine components like flywheel, starter housing, and air cleaner.

ENGINE COMPONENTS LIST (Page 32)

Comprehensive list of engine parts with key numbers and descriptions.

ENGINE COMPONENTS LIST (Page 33)

Continuation of the comprehensive engine parts list.

WARRANTY INFORMATION

GENERAL WARRANTY TERMS

General conditions, exclusions, and repair terms for product warranties.

WARRANTY PERIODS AND CUSTOMER RESPONSIBILITIES

Lists applicable warranty periods and owner's obligations.

SERVICE NOTES
