Part name Order number Quantity
Frame - FFC - Grey sm.001.016 1
Bearing - anged - belt_F624Z bm.001.004 * 8
Screw - Washer M4 - DIN125_M4_200HV sc.001.002 4
Screw - Allen key M4L1 6 - DIN912_M4L1 6 Nickel plated sc.002.015 4
Power supply - 24V - assy pr.001.045 * 1
... Power supply - 24V 14A be.000.013 1
... Cable - Flat power Cable ca.001.002 1
... Sticker - Electric shock pt.000.002 1
Screw - Flat head countersunk M4L6 - DIN7991 _M4L6 sc.002.020 4
Cable - Power switch 24V ca.000.007 * 1
Screw - Washer M3 - DIN125_M3 sc.001.001 1
Screw - Nut M3 - DIN934_M3 sc.003.002 2
Rod - Z - 12/268mm bm.001.007 * 2
Screw - Allen key M3L4 - DIN912_M3L4 Nickel plated sc.002.011 4
Z bush bm.001.010 * 2
Z screw - assy pr.001.052 * 1
... ma19 Z screw ma.001.013 1
... Screw - Set screw M3L4 - DIN913_M3L4 at sc.002.004 2
... Pulley GT2 20 teeth bm.000.024 1
... ma19 Z holder ma.001.011 1
... ma19 Z coupler ma.001.010 1
... ma19 Z nut ma.001.012 1
Timing belt - closed 126mm by.001.006 * 1
Z Console assy pr.001.051 1
... Block Z left pr.001.009 1
... ... ma19 Block Z ma.001.003 1
... ... Bearing - LM12UU - Linear Bearing bm.001.002 * 2
... ... Screw - Set screw M3L4 - DIN913_M3L4 at sc.002.004 2
... ... Screw - Allen key M3L6 - DIN912_M3L6 Nickel plated sc.002.012 2
... ... Z horse CBP painted sp.001.012 1
... Screw - Allen key M4L8 - DIN912_M4L8 Black sc.002.016 8
... Z Console painted sp.001.013 1
... Block Z Right pr.001.010 1
... ... ma19 Block Z ma.001.003 1
... ... Bearing - LM12UU - Linear Bearing bm.001.002 * 2
... ... Screw - Flat head countersunk M3L6 - DIN7991 _M3L6 sc.002.018 2
... ... Energy chain - 7.7 1st end bm.000.010 * 1
... ... Screw - Set screw M3L4 - DIN913_M3L4 at sc.002.004 2
Base bed assy pr.001.004 * 1
... sm23_bed_base sm.001.026 1
... Bed heater Connector ATX be.000.011 * 1
... Energy chain - 7.7 2nd end bm.000.011 1
... Energy chain - 7.7 9pcs bm.000.012 1
... Cable gasket, Rubber bm.000.020 * 2
... sm23_hot sticker holder sm.000.003 1
4. Spare parts overview
