Assembly
Unpacking
This product requires assembly.
• Carefully remove the product and any accessories from the box. Make sure
that all items listed in the packing list are included.
WARNING!
Do not use this product if any parts on the Packing List are
already assembled to your product when you unpack it.
Parts on this list are not assembled to the product by the
manufacturer and require customer installation. Use of a
product that may have been improperly assembled could
result in serious personal injury.
• Inspect the product carefully to make sure no breakage or damage
occurred during shipping.
• Do not discard the packing material until you have carefully inspected and
satisfactorily operated the product.
WARNING!
If any parts are damaged or missing, do not operate this
product until the parts are replaced. Use of this product with
damaged or missing parts could result in serious personal
injury.
WARNING!
Do not attempt to modify this product or create accessories
not recommended for use with this string trimmer. Any such
alteration or modication is misuse and could result in a
hazardous condition leading to possible serious personal
injury.
WARNING!
To prevent accidental starting that could cause serious
personal injury,always remove the battery pack from the
product when assembling parts.
Attach the guard(see Figure 2)
WARNING!
Avoid contact with the blade. Failure to avoid contact can
result in serious personal injury.
1 Invert the string trimmer to access the trimmer head.
2 Put the lower shaft into the groove of the guard.
3 Insert the bracket into the slot. Align the screw holes on the bracket with the
screw holes on the guard.
4 Install and tighten the screws.
Attaching the auxiliary handle (see Figure 3)
1 Put the auxiliary handle into the groove of the lower clamp.
2 Put the upper clamp onto the handle. Make sure the handle is installed in
the groove.
