Tourno pick-up
Original Operation Manual English
- 11 -
5 Operation
5.1 Start and stop
Start
1. Release parking brake
2. Set throttle to Choke
3. Put ignition key into ignition lock
4. Turn ignition key to Start
5. The machine is now running
6. After a short time, move throttle to Full throttle position
Stop
1. Set throttle to Idle
2. Turn ignition key to Stop
3. The machine is out of operation now
Emergency stop
• Turn ignition key to Stop
5.2 Normal operation
WARNING !
Risk of injuries by highly flammable
materials and heat!
Materials hitting a hot surface may result in serious burns
on the body when they inflame; e.g. hot or burning materials
such as coal.
Keep away highly flammable materials from the
machine.
Do not move the machine over any spilled fuel or similar
substances.
1. Basic setting:
• Park machine on an even surface
• Refill consumables
• Set throttle to Stop
• Fix mounting devices as required
2. Start the machine.
• Release parking brake
• Set throttle to Choke on operating panel
• Put ignition key into ignition lock and turn to Start to start
the machine
• Let the motor run for a short time
• Only then move throttle to Full throttle
• In the Full throttle position, accessories may be used.
Forward drive
Press the right upper part of the foot pedal downward
Backward drive
Press the right lower part of the foot pedal downward
3. Stop machine.
• Bring machine to a stop
• Set throttle to Idle
• Turn ignition key to Stop to put the machine out of
operation
• Remove ignition key
5.3 Activities after use
1. Stop the motor.
2. Roughly remove dirt and sand by using a soft hand
brush.
3. Check machine condition; remedy damage to paint
coating, if any
4. The machine must be left in a clean and dry condition.
