TRANSMITTER SELECT SWITCH [2]
Each C.A.S.T. port on N8 has a small toggle switch
that is used to determine which audio path is sent
out from N8’s Inputs, through C.A.S.T., and to the
outputs of the connected C.A.S.T. devices.
By default, each C.A.S.T. connection has its own set
of discrete audio outputs however, by using the
Transmitter Select switch [2], all of the C.A.S.T. ports
can be configured to receive channels 1-2
connected to the rear DB25 Input Connector [3].
This is perfect for talkback routing, creating zones,
or any application where all C.A.S.T. devices
connected to N8 must receive the same output
signal.
Page 5 ©2022 Cranborne Audio Ltd
