Crane DISC GOLF SET - Assembly Instructions; Leg Assembly

Assembly
1. Insert the Small Poles (#4) into the 3 Way Cap Connectors (#6). (See FIG. 1A.)
2. Insert the Bottom Pole (#P1) into the Round Leg Cap (#7). (See FIG. 2D.)
3. Repeat for all 3 legs.
FIG. 1
FIG. 2
Disc Golf Set Assembly
4 AFTER SALES SUPPORT
mmdservice@themdsports.com
1-877-852-8164
6
4
6
4
4
FIG. 1A
7
7
FIG. 2D
FIG. 2A
FIG. 2B
1
Close Pin Lock
Bottom Pole
Keep Pin Locks
open
FIG. 2C
P3
P1
P1
P1
P3
P2
P3
