GTD65 Guitar Amplifier w/DSP and Channel Tracking
System Block Diagram
10
INPUT
CLEAN/
OVERDRIVE
LOWVOLUME MID HIGH
REVERB
BUFFER
MIX
AMP
CLEAN
DAMPING
CIRCUIT
POWER
AMP
EXT.
SPEAKER
SPEAKE
R
OVERDRIVE/
HIGH GAIN
INSERT
HIGH GAIN
GAIN
OVERDRIVE
LEVEL
HIGH GAIN
LEVEL
OVERDRIVE
GAIN
MIDLOW HIGH
SHAPE
SLAP
ECHO
ECHO/EFF
TUNER
CD
INPUT
CHORUS
FLANGER
PHASER
DSP
CHORUS DELAY
MIX
AMP
