GX-20M/R Guitar Amplifier
7
CHORUS
GX-20M
ONLY
INPUT
LEVEL
OVERDRIVE
SELECT
FLEX WAVE
STAGE
TONES
DAMPING
ATTENUATOR
LOW
MID HIGH
REVERB
GAIN LEVEL
BUFFER
POWER
AMP
EXT.
SPEAKER
PHONES
SPEAKER
"CLEAN"
"OVERDRIVE"
ON
SYSTEM BLOCK DIAGRAM:
