Made in Indonesia - r01 Page 2 of 4
SLOANE
GREY/MAHOGANY LEANING DESK
C
B
top
crossbar
left
upright
shelves
Customer Service 800.967.6696 | Latest instructions available at www.crateandbarrel.com
A
C
top
crossbar
right
upright
B
A
desktop
4 Attach 2 right/left desktop brackets to the bottom of
assembled unit as shown with 8 small screws per
bracket. Do not fully tighten each screw before all the 8
screws are attached. At this point, secure screws with a
screwdriver. Position unit upright.
Assembly is now complete.
2 A) Fit dowels of top crossbar
into right upright. Secure top
crossbar with 1 large bolt as
shown, using a phillips head
screwdriver.
B) Position right upright with 2
shelves (in descending depths)
and 1 desktop as shown. Place
the shortest depth shelf at the top
of the uprights, and desktop at
the bottom.
C) Insert 1 small bolt through
each shelf and desktop side.
Secure each screw with an allen
wrench.
3 A) Fit dowels of top crossbar into left upright. Secure
top crossbar with 1 large bolt as shown, using a phillips
head screwdriver.
B) Position left upright with 2 shelves and a desktop as
shown.
C) Insert 1 small bolt through each shelf and desktop side.
Secure each screw with an allen wrench. Position unit
upright.
rear
right desktop
bracket
front
NOTE: Do not fully
tighten the screws until
all 8 screws are inserted
into each bracket
A
large bolt
To Next Page
