Create Room Cubby - Step 2: Attach Cams to Base; Step 3: Connect Sides to Base

2
Turn over your Base panel. With bottom side up, insert cams
by hand, as indicated below. Do not attempt to tighten.
2
x6
Cams
Base
(underneath)
3
Connect Side 1 and Side 2 with the Base, one at a time
by lining up the posts and dowels with the corresponding
holes and tapping firmly into place.
Base
Side 1
Side 2
Check that you are installing the
sides panels correctly by ensuring
that there is a smaller gap between
the peg holes and the bottom edge
than the peg holes and the top edge.
Once connected, use your screw driver to gently turn
cam 220 degrees clockwise to lock into position.
