2
RIGHT SIDE DREAMBOX ATTACHMENT
(turn Top so that side table hinge holes are on the right)
Side Table Hinge Holes
Top
Side Table Hinge Holes
Top
LEFT SIDE DREAMBOX ATTACHMENT
(turn Top so that side table hinge holes are on the left)
x7
Connecting
Bolts
x7
Connecting
Bolts
Insert connecting bolts depending on
corresponding attachment. Install door catch.
x1
Door Catch
x1
Door Catch
2
x2
1/2” Screws
x2
1/2” Screws
