8
ENGLISH
FACILITY
1. Mark on the wall the 4 holes to be made with the drill. The horizontal separation between
the holes must be 450 mm and vertically 745 mm.
2. Once the holes have been marked, drill the 4 holes of 8 mm diameter.
3. Detach the wall brackets as shown in the
image.
4. Insert the plug into the wall hole, then
attach the outer accessory to the wall
brackets and use the wall screw to x
the accessory properly. Repeat the step
for the rest of the holes.
5. Fix the internal accessories and the 4
front accessories to the towel rack with
the screws, then attach the decorative
cover so that the screw is not visible.
6. Once the accessories are attached to
the towel rack, insert the internal acces-
sories to the external ones on the wall,
adjust the distance you want and x the
xing screws so that it is well secured.
CEILING CEILING
FLOOR FLOOR
External
accessory
Internal
accessory
Front
attachment
Top Screw
Wall
Wall
>150 mm
>150 mm
ø8mm
450 mm
745 mm
>150 mm
>150 mm
745 mm
