Note: It is vital that the fort
be level after this
phase!
N
o
t
e
!
I
m
p
o
r
t
a
n
t
MAKE SURE FRAME IS
SQUARE BEFORE
PROCEEDING TO
NEXT PHASE!
(78)
a3
HARDWARE NEEDED
ITEMS NEEDED
(11) WF14 Floor Board-A 1×4×56 1/8
(1) WF15a Floor Board-B 1× 4× 56 1/8
(1) WF16 Floor Boardb-D 1×6×56 1/8
a3
(1) WF15b Floor Board -C 1× 4× 56 1/8
WD14
WD115b
WD15a
WD16
5STEP :
WD07
WD03
* Lay WF15a, WF15b, WF16 in its rightful place as shown.
TOWER ASSEMBLY
* Lay all eleven WF14 in between to from the tower deck.
* Once all slats are in place, make sure all slats are flush on the left and right side of the tower.
* Once all slats are are flush secure slats with wood screw "a3".
going into the suport below.
Make sure "a3" wood screws are
