HARDWARE NEEDED
WD39
ITEMS NEEDED
(2) WD38 Rockwall Rail 5/4×4×59 3/4
WD38
(8) WD39 Rockwall Board-A 1×4×21
(8) WD40 Rockwall Board-B 1×4×21
(1) WC42 Rockwall Board-C 1×3×21
(8)
e9
d2
(8)
c1
k1
(8)
(8)
k3
(8)
(68)
a3
k4
(8)
N
o
t
e
!
I
m
p
o
r
t
a
n
t
Note orientation
ROCK ATTACHMENT
ROCKWALL BOARD
CLIMBING ROCK
ROCKWALL
ASSEMBLY
* Create the rockwall by attaching two WD38 with seventeen rockwall boards. Note the orientation of the holes.
* Suggestion: Line up all the rockwall boards and make sure, they are all flush before securing with wood screws "a3" .
* From the back of assembled rock wall insert nut barrel "d2".
* Install the climbing rocks ( See detail diagram below ).
Top of Rockwall
30
(8) B10LGR
To Next Page
